Model N2101

Inclination sensor

X/Y/Z direction, -45 ... +45°

Selected documents
Sales contact Questions? Find a contact in your vicinity.


  • Crane systems
  • Mobile cranes
  • Ship cranes
  • Aerial platforms
  • Solar collectors

Special features

  • Measuring range freely selectable between -45 ... +45°
  • Relative linearity error < 0.1 % of FS over the entire measuring range
  • Good damping behaviour, no gravitational acceleration error
  • Resistant to seawater, IP67
  • 2 axes freely selectable


The two directions of rotation can be selected freely (X, Y, Z direction) in this inclination sensor. They detect the orientation angle of an object in relation to the gravitational field of the earth.

The sensor has a measuring range of max. -45 ... +45° and offers an extraordinarily high accuracy and precision over the entire measuring range. The measured value resolution is 0.01°.

Inclination sensor
